Description
The Morrison Bros FIG 285AL is a lightweight aluminum Y-type bottom clean-out line strainer rated to 50 PSI operating pressure. Its bottom-access design allows the stainless steel strainer basket to be removed for cleaning or replacement without disturbing the pipeline. Available in 1-1/2″” to 3″” NPT with standard or PTFE gasket options and stainless steel screens ranging from 6 to 100 mesh.
Features
- Y-type body for efficient inline straining
- Bottom clean-out design for easy basket access and servicing
- Rated to 50 PSI operating pressure
- Lightweight aluminum body and cap
- Stainless steel set screw and nut for yoke
- Stainless steel screens available in 6, 10, 20, 40, 60, 80, or 100 mesh
- Standard and PTFE gasket configurations available
- Less-screen variants available for custom screen installations
Applications
- Pipeline installations requiring inline debris filtration
- Protection of downstream pumps, meters, and process equipment
- Fuel, water, and general liquid handling systems
